In connection with a Y-axis in every spindle position as standard, highly complex workpieces can be fully processed using standard tools with these turning machines: With these machines, DMG MORI combines SWISSTYPE technology with the productivity of a multi-spindle turning machine.

#3 axis cnc mill dmg series

Our CNC-driven multi-spindle automatic turning machines in the MULTISPRINT series are totally unique. The machine can be converted in less than 30 minutes with this. The highlight is the SWISSTYPEkit, which allows both short and long turning to be carried out on the same machine. These can be used to drive up to ten tools. Up to 28 tool positions on three independent linear carriers are available for processing complex workpieces. They have five or six linear axes, as well as up to two C-axes. Our automatic turning machines in the SPRINT series (SPRINT 20 and SPRINT 32) allow you to process workpieces with a diameter of up to 20 and 32 mm, respectively, and a length of up to 600 mm. Our production turning machines with revolver: The turning machines in the NZX-S series and the CTX beta 1250 CS are designed for manufacturing crankshafts or camshafts. On the other hand, this enables the collision-free front machining of long parts on the main spindle and counter-spindle. On the one hand, you can process long workpieces, such as shafts, on our turning machines with the support of the tailstock on a four-axis basis. This unique workspace concept with two revolvers and the cross stroke of the counter-spindle and tailstock combination makes possible processing in two independent workspaces in parallel. It should also be noted that the two-revolver version also uses the TWIN concept that is available for our production turning machines. In addition, the versions are available with three revolvers without a B-axis and with two revolvers. Thanks to up to three tool carriers, our horizontal lathes are perfect for the series production of both bars and feed components. Our revolver production turning machines have up to three revolvers with three Y-axes and a built-in B-axis. Horizontal production turning with revolvers

Additional lower revolver as a second tool carrier for productive four-axis processing.

36-month warranty on all MASTER spindles with no usage hours limit.

Turning spindles in the turnMASTER series with up to 1,194 Nm torque.

B-axis with the compactMASTER Turn & Mill spindle for five-axis simultaneous processing at up to 220 Nm.

One machine for lots of work steps with our high-performing Turn & Mill machines in the CTX TC, NT and NTX series.

The advantages of our Turn & Mill centres: This means the lathes in the CTX TC, NT and NTX series also facilitate the five-axis CNC milling of complex workpieces along with free-form surfaces. The built-in B-axis is fitted with a direct drive. Equipped with the counter-spindles that are available, these turning/milling centre workpieces can be fully processed from all six sides.

Our Turn & Mill turning machines in the CTX TC, NT and NTX series allow turning and milling capabilities in one machine. MASTERspindles with a 36-month guarantee and no usage hours limitĭMG MORI makes turning machines in the following series:.Flat track for optimum attenuation properties and dynamic rigidity.Processing of workpieces up to 930 mm in diameter and a turning length of up to 6,000 mm.Big-bore spindles with an outlet of up to 375 millimetres in diameter.Y-axis for eccentric milling processing of complex workpieces.

#3 axis cnc mill dmg full

Counter-spindle for six-side full processing.

A large turning diameter of up to 930 mm, optimum chip fall, and measuring systems by MAGNESCALE for extremely precise results also ensure that these turning machines stand out from the crowd: The highest-possible cutting performance is ensured by spindle drives of up to 12,080 Nm. These lathes are true all-rounders and the backbone of many production operations: CNC-controlled universal turning machines by DMG MORI.

In 96 per cent of cases, replacement parts are available immediately.

Spindlereplacement within 24 hours or repair.

Individual configuration to meet your specific requirements.

High-performance, flexible, and easy-to-operate lathes.

To ensure that your machines can be operated seamlessly, we provide you with a service package you can rely on day and night.īenefits of our turning machines at a glance: This is made possible by our modular system with high-tech components that can be adapted to meet your individual requirements. DMG MORI can provide you with the most up-to-date, high-performance and innovative CNC turning machines in the design you need for your production. Regardless of whether they are for use in the automobile industry, engineering, medical technology or other manufacturing and production applications in metalworking: lathes are needed everywhere turned parts are manufactured.
